Same model may have multiple batches, images only for reference.

IRF1010EZS

Name: IRF1010EZS
Brand: Infineon Technologies
SKU: 604180
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF1010EZS
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	AUTOMOTIVE MOSFET \| MOSFET N-CH 60V 75A D2PAK
Datasheet	IRF1010EZS Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube
Status	Obsolete
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	60V
Id - Continuous Drain Current	75A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	8.5mOhm at 51A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 100μA
Gate Charge (Qg) (Maximum) at Vgs	86nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	2810pF at 25V
Power Dissipation (Maximum)	140W
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	SMD
Supplier Device Package	D2PAK
Manufacturer Package	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Manufacturer Pack Quantity	50
MSL Level	1 (Unlimited)
Win Source Part Number	1186868-IRF1010EZS
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRF1010EZS CAD Model

Alternative Products

Description

The Infineon Technologies 1186868-IRF1010EZS is a high-quality N-Channel MOSFET transistor designed for use in a wide range of electronic applications.

Transistor Type: N-Channel MOSFET
Features: Low on-resistance, compact size, low power consumption
Ideal For: High-power applications, portable devices
Package: D2PAK
Supply and Demand Status: Balanced
Popularity: Medium
