The IRF6892STRPBF is a single N-channel MOSFET transistor from the HEXFET series manufactured by Infineon Technologies.

• FET Type: N-Channel
• FET Feature: Logic Level Gate
• Drain to Source Voltage (Vdss): 25V
• Current - Continuous Drain (Id) @ 25° C: 28A (Ta), 125A (Tc)
• Rds On (Max) @ Id, Vgs: 1.7mOhm @ 28A, 10V
• Vgs(th) (Max) @ Id: 2.5V @ 250µA
• Gate Charge (Qg) @ Vgs: 25nC @ 4.5V
• Input Capacitance (Ciss) @ Vds: 2510pF @ 13V
• Power - Max: 3.8W (Ta), 110W (Tc)
• Mounting Type: Surface Mount
• Package / Case: DirectFET™ S1
• Supplier Device Package: DirectFET™ S1
• Operating Temperature: -40°C ~ 150°C (TJ)
