Same model may have multiple batches, images only for reference.

IRF6894MTRPBF

Name: IRF6894MTRPBF
Brand: Infineon Technologies
SKU: 159798
Availability: InStock
Rating: 4.93 (73 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF6894MTRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 25V 32A DIRECTFET
Datasheet	IRF6894MTRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	25V
Continuous Drain Current at 25°C	32A (Ta), 160A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.1V @ 100μA
Max Gate Charge	39nC @ 4.5V
Max Input Capacitance	4160pF @ 13V
Maximum Gate-Source Voltage	±16V
FET Feature	Schottky Diode (Body)
Power Dissipation (Max)	2.1W (Ta), 54W (Tc)
Maximum Rds On at Id,Vgs	1.3 mOhm @ 33A, 10V
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	DIRECTFET MX
Dimension	DirectFET Isometric MX
Win Source Part Number	133174-IRF6894MTRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRF6894M
Introduction Date	January 28, 2011
ECCN	EAR99
Country of Origin	Mexico
Halogen Free	Not Compliant
Estimated EOL Date	2019
Ultra Librarian 3D Model	Ultra Librarian IRF6894MTRPBF CAD Model

Alternative Products

Description

The 133174-IRF6894MTRPBF is an N-channel MOSFET from Infineon Technologies with a maximum power dissipation of 2.1W (Ta) and 54W (Tc).

Drain-Source Breakdown Voltage: 25V
Continuous Drain Current: 32A (Ta) and 160A (Tc) @ 25°C
Package: DIRECTFET MX package
Product Category: discrete semiconductor product
Product Status: active
Operating Temperature Range: -40°C to 150°C (TJ)
Market Popularity: high
Alternative parts: IRF6894MTR1PBF and IRF6894MPbF
