Same model may have multiple batches, images only for reference.

IRF7416TRPBF

Name: IRF7416TRPBF
Brand: Infineon Technologies
SKU: 159933
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF7416TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 10A 8-SOIC
Datasheet	IRF7416TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	10A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	92nC @ 10V
Max Input Capacitance	1700pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	20 mOhm @ 5.6A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	015767-IRF7416TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	IRF7416
Introduction Date	June 06, 2005
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian IRF7416TRPBF CAD Model

Description

The Infineon Technologies IRF7416TRPBF is a P-Channel MOSFET, which is widely used in Discrete Semiconductor Products.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 10A @ 25°C
Power Dissipation: 2.5W (Ta)
Gate-Source Threshold Voltage: 1V @ 250μA
Max Gate Charge: 92nC @ 10V
Maximum Rds On @ Id,Vgs: 20 mOhm @ 5.6A, 10V
Package: 8-SO
Operating Temperature Range: -55°C to 150°C (TJ)
Part Usage: common-used
Popularity: high
Supply and Demand Status: sufficient
Estimated EOL date: 2024
