Same model may have multiple batches, images only for reference.
IRF7815TRPBF Real Image IRF7815TRPBF Real Image1 IRF7815TRPBF Real Image2 IRF7815TRPBF Real Image3 IRF7815TRPBF Real Image4
IRF7815TRPBF Real Image IRF7815TRPBF Real Image1 IRF7815TRPBF Real Image2 IRF7815TRPBF Real Image3 IRF7815TRPBF Real Image4
Same model may have multiple batches, images only for reference.

IRF7815TRPBF

Part No IRF7815TRPBF
Manufacturer Infineon Technologies
Catalog FETs - Single
Description MOSFET N-CH 150V 5.1A 8-SOIC
Datasheet
IRF7815TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 150V
Id - Continuous Drain Current 5.1A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 43mOhm at 3.1A, 10V
Gate Source Voltage(th) (Maximum) at Id 5V at 100μA
Gate Charge (Qg) (Maximum) at Vgs 38nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 1647pF at 75V
Power Dissipation (Maximum) 2.5W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package 8-SO
Manufacturer Package 8-SOIC
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 738795-IRF7815TRPBF
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF7815TRPBF CAD Model

Description

The IRF7815TRPBF is an N-channel MOSFET manufactured by Infineon Technologies. It features a drain-source breakdown voltage of 150V and a continuous drain current of 5.1A.

  • Drain-Source Breakdown Voltage: 150V
  • Continuous Drain Current: 5.1A
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Input Capacitance: 1647pF @ 75V
  • Package: 8-SO
  • Popularity: Low
  • Supply and Demand Status: Limited
