Same model may have multiple batches, images only for reference.

IRF9317TRPBF

Name: IRF9317TRPBF
Brand: Infineon Technologies
SKU: 160165
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF9317TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 16A 8-SOIC
Datasheet	IRF9317TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	16A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.4V @ 50μA
Max Gate Charge	92nC @ 10V
Max Input Capacitance	2820pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	6.6 mOhm @ 16A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	017556-IRF9317TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRF9317TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies P-Channel MOSFET is a high-performance component designed to operate in a temperature range of -55°C to 150°C (TJ).

Maximum Power Dissipation: 2.5W (Ta)
Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 16A (Ta)
Gate-Source Threshold Voltage: 2.4V @ 50μA
Maximum Gate Charge: 92nC @ 10V
Maximum Input Capacitance: 2820pF @ 15V
Maximum Rds On: 6.6 mOhm @ 16A, 10V
Popularity: High
