Same model may have multiple batches, images only for reference.

IRFR3711ZTRPBF

Name: IRFR3711ZTRPBF
Brand: Infineon Technologies
SKU: 160785
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRFR3711ZTRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 20V 93A DPAK
Datasheet	IRFR3711ZTRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	93A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.45V @ 250μA
Max Gate Charge	27nC @ 4.5V
Max Input Capacitance	2160pF @ 10V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	79W (Tc)
Maximum Rds On at Id,Vgs	5.7 mOhm @ 15A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D-Pak
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	001282-IRFR3711ZTRPBF
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRFR3711ZTRPBF CAD Model

Alternative Products

Description

The Infineon Technologies 001282-IRFR3711ZTRPBF MOSFET is a high-performance N-Channel MOSFET that is ideal for use in a wide range of applications.

Maximum Power Dissipation: 79W (Tc)
Drain-Source Breakdown Voltage: 20V
Continuous Drain Current: 93A (Tc) @ 25°C
Maximum Rds On: 5.7 mOhm @ 15A, 10V
Gate-Source Threshold Voltage: 2.45V @ 250μA
Maximum Gate Charge: 27nC @ 4.5V
Maximum Input Capacitance: 2160pF @ 10V
Package: D-Pak
Ideal for use in: discrete semiconductor products
