IRFR540ZTRPBF Infineon Technologies IRFR540ZTRPBF Real Image IRFR540ZTRPBF label picture
Same model may have multiple batches, images only for reference.
IRFR540ZTRPBF Infineon Technologies IRFR540ZTRPBF Real Image IRFR540ZTRPBF label picture
IRFR540ZTRPBF Infineon Technologies IRFR540ZTRPBF Real Image IRFR540ZTRPBF label picture
Same model may have multiple batches, images only for reference.

IRFR540ZTRPBF

Part No IRFR540ZTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH Si 100V 35A Automotive 3-Pin(2+Tab) DPAK T/R / MOSFET N-CH 100V 35A DPAK
Datasheet
IRFR540ZTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 35A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 50μA
Max Gate Charge 59nC @ 10V
Max Input Capacitance 1690pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 91W (Tc)
Maximum Rds On at Id,Vgs 28.5 mOhm @ 21A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1047081-IRFR540ZTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRFR540Z
Introduction Date February 03, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRFR540ZTRPBF CAD Model

Description

The IRFR540ZTRPBF is a N-channel MOSFET transistor manufactured by Infineon Technologies.

  • Manufacturer: Infineon Technologies
  • Channel Type: N-channel
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: Up to 35A @ 25°C
  • Maximum Rds On: 28.5 mOhm @ 21A, 10V
  • Gate-Source Threshold Voltage: 4V @ 50μA
  • Maximum Gate Charge: 59nC @ 10V
  • Applications: Suitable for use in various applications such as power supplies, motor control, and DC-DC converters.
  • Package: D-Pak package
  • Compliance: Compliant with halogen-free requirements
  • Estimated EOL Date: 2027
