IRLL024ZTRPBF Real Image IRLL024ZTRPBF Real Image1 IRLL024ZTRPBF Real Image2 IRLL024ZTRPBF Real Image3 IRLL024ZTRPBF Real Image4 IRLL024ZTRPBF Real Image5
Same model may have multiple batches, images only for reference.
IRLL024ZTRPBF Real Image IRLL024ZTRPBF Real Image1 IRLL024ZTRPBF Real Image2 IRLL024ZTRPBF Real Image3 IRLL024ZTRPBF Real Image4 IRLL024ZTRPBF Real Image5
IRLL024ZTRPBF Real Image IRLL024ZTRPBF Real Image1 IRLL024ZTRPBF Real Image2 IRLL024ZTRPBF Real Image3 IRLL024ZTRPBF Real Image4 IRLL024ZTRPBF Real Image5
Same model may have multiple batches, images only for reference.

IRLL024ZTRPBF

Part No IRLL024ZTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 55V 5A SOT223
Datasheet
IRLL024ZTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 55V
Continuous Drain Current at 25°C 5A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 11nC @ 5V
Max Input Capacitance 380pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 1W (Ta)
Maximum Rds On at Id,Vgs 60 mOhm @ 3A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Dimension TO-261-4, TO-261AA
Win Source Part Number 017757-IRLL024ZTRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRLL024ZTRPBF CAD Model

Description

The Infineon Technologies IRLL024ZTRPBF MOSFET is a N-Channel polarity electronic component manufactured by Infineon Technologies.

  • Polarity: N-Channel
  • Power Dissipation: 1W (Ta)
  • Drain-Source Breakdown Voltage: 55V
  • Continuous Drain Current: 5A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Maximum Rds On: 60 mOhm @ 3A, 10V
  • Package: SOT-223
  • Temperature Range: -55°C to 150°C (TJ)
