SPP06N80C3 Infineon Technologies SPP06N80C3 label picture SPP06N80C3 Real Image1 SPP06N80C3 Real Image2 SPP06N80C3 Real Image3 SPP06N80C3 Real Image4 SPP06N80C3 Real Image5
Same model may have multiple batches, images only for reference.
SPP06N80C3 Infineon Technologies SPP06N80C3 label picture SPP06N80C3 Real Image1 SPP06N80C3 Real Image2 SPP06N80C3 Real Image3 SPP06N80C3 Real Image4 SPP06N80C3 Real Image5
SPP06N80C3 Infineon Technologies SPP06N80C3 label picture SPP06N80C3 Real Image1 SPP06N80C3 Real Image2 SPP06N80C3 Real Image3 SPP06N80C3 Real Image4 SPP06N80C3 Real Image5
Same model may have multiple batches, images only for reference.

SPP06N80C3

Part No SPP06N80C3
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 800V 6A TO-220AB
Datasheet
SPP06N80C3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 800V
Continuous Drain Current at 25°C 6A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 3.9V @ 250μA
Max Gate Charge 41nC @ 10V
Max Input Capacitance 785pF @ 100V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 83W (Tc)
Maximum Rds On at Id,Vgs 900 mOhm @ 3.8A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package PG-TO-220-3
Dimension TO-220-3
Win Source Part Number 065953-SPP06N80C3
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SPP06N80C3 CAD Model

Description

The Infineon Technologies MOSFET is an N-channel transistor with a maximum drain-source breakdown voltage of 800V and a continuous drain current of 6A.

  • Maximum Drain-Source Breakdown Voltage: 800V
  • Continuous Drain Current: 6A
  • Maximum Gate-Source Voltage: ±20V
  • Input Capacitance: 785pF @ 100V
  • Gate Charge: 41nC @ 10V
  • Package: PG-TO-220-3
  • Maximum Power Dissipation: 83W
  • Supply and Demand Status: Limited
  • Operating Temperature: -55°C and 150°C
