Same model may have multiple batches, images only for reference.
N80C186XL20 real image
Same model may have multiple batches, images only for reference.

N80C186XL20

Part No N80C186XL20
Manufacturer Intel
Catalog Embedded - Microprocessors
Description 80C186 Microprocessor IC i186 1 Core, 16-Bit 20MHz 68-PLCC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family Embedded - Microprocessors
Manufacturer Intel
Series i186
Packaging Tube
Core Processor 80C186
Number of Cores/Bus Width 1 Core, 16-Bit
Speed 20MHz
Co-Processors/DSP Math Engine; 80C187
RAM Controllers DRAM
Graphics Acceleration No
Voltage - I/O 5.0V
Operating Temperature Range 0°C ~ 70°C (TA)
Package 68-LCC (J-Lead)
Manufacturer Device Package 68-PLCC
Win Source Part Number 024704-N80C186XL20
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian N80C186XL20 CAD Model

Description

This component is manufactured by Intel and is a reliable choice for your electronic projects.

  • Series: i186
  • Speed: 20MHz
  • Core: 1
  • Bus Width: 16-bit
  • Temperature Range: 0°C to 70°C
  • Voltage: 5.0V
