The 2SA1283 is a PNP epitaxial silicon transistor manufactured by ISAHAYA. It's designed for use in audio frequency power amplifier applications. The transistor features high collector power dissipation and good linearity.

Applications

• Audio Power Amplifiers
• Output Stage Amplifiers
• General Purpose Amplification
• Driver Stage Amplifiers

Features

• PNP Epitaxial Silicon Transistor
• High Collector Power Dissipation
• High Collector Current
• Low Saturation Voltage
• High hFE (DC Current Gain)

Benefits

• High power handling capability suitable for audio power amplifiers.
• Low distortion characteristics ensure high-fidelity audio reproduction.
• Good gain linearity contributes to overall amplifier performance.
• Can deliver substantial output power.

Additional Details

The 2SA1283 is typically used in complementary pairs with NPN transistors in audio amplifier circuits. It requires appropriate heat sinking to manage its power dissipation. The transistor's voltage and current ratings must be considered when designing the amplifier circuit. The package type is often a TO-3P or similar through-hole package. It is important to use proper biasing techniques to ensure stable operation and minimize distortion. It should be handled carefully to avoid electrostatic discharge (ESD) damage. The transistor's characteristics are crucial for achieving the desired amplifier performance. This device is now considered obsolete, so replacement/alternate components may be required for new designs. Its fT is around 30MHz. It has a VCE of -180V.
