Same model may have multiple batches, images only for reference.

IXTP96P085T

Name: IXTP96P085T
Brand: IXYS
SKU: 1278259
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IXTP96P085T
Manufacturer	IXYS
Catalog	Transistors - FETs, MOSFETs - RF
Datasheet	IXTP96P085T Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	IXYS
Series	TrenchP™
Package	Tube
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	85 V
Current - Continuous Drain (Id) @ 25°C	96A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	13mOhm @ 48A, 10V
Vgs(th) (Max) @ Id	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	180 nC @ 10 V
Vgs (Max)	±15V
Input Capacitance (Ciss) (Max) @ Vds	13100 pF @ 25 V
Power Dissipation (Max)	298W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-220-3
Package / Case	TO-220-3
Base Product Number	IXTP96
Standard Package	50
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	1278259-IXTP96P085T
Ultra Librarian 3D Model	Ultra Librarian IXTP96P085T CAD Model

Alternative Products

Description

The IXTP96P085T is a P-Channel MOSFET transistor from the TrenchP™ series of IXYS.

Drain to Source Voltage: 85 V
Continuous Drain Current: 96A @ 25°C
Maximum On-Resistance: 13mOhm @ 48A and 10V gate-source voltage
Gate Threshold Voltage: 4V @ 250μA
Maximum Gate-Source Voltage: ±15V
Maximum Power Dissipation: 298W @ Tc
Package: Through-hole TO-220-3
Gate Charge: 180nC @ 10V
Input Capacitance: 13100pF @ 25Vds
Operating Temperature Range: from -55°C to 150°C (TJ)
REACH: Unaffected
