MMIX1F180N25T

Part No MMIX1F180N25T
Manufacturer IXYS
Catalog Transistors – FETs, MOSFETs – Single
Description MOSFET N-CH 250V 132A 24SMPD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 250 V
Current - Continuous Drain (Id) @ 25°C 132A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 13mOhm @ 90A, 10V
Vgs(th) (Max) @ Id 5V @ 8mA
Gate Charge (Qg) (Max) @ Vgs 364 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 23800 pF @ 25 V
Power Dissipation (Max) 570W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 24-SMPD
Case / Package 24-PowerSMD, 21 Leads
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1495168-MMIX1F180N25T
Ultra Librarian 3D Model Ultra Librarian MMIX1F180N25T CAD Model
