Same model may have multiple batches, images only for reference.

EC2-12SNU

Name: EC2-12SNU
Brand: Kemet
SKU: 587904
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	EC2-12SNU
Manufacturer	Kemet
Catalog	Signal Relays, Up to 2 Amps
Description	RELAY GEN PURPOSE DPDT 2A 12VDC / General Purpose Relay DPDT (2 Form C) Through Hole
Datasheet	EC2-12SNU Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Relays - Signal Relays, Up to 2 Amps
Mfr	KEMET
Series	EC2
Package	Tube
Product Status	Active
Mounting Type	Through Hole
Coil Voltage	12VDC
Contact Form	DPDT (2 Form C)
Contact Rating (Current)	2 A
Switching Voltage	250VAC, 220VDC - Max
Coil Current	8.3 mA
Coil Type	Latching, Single Coil
Termination Style	PC Pin
Must Operate Voltage	9 VDC
Operate Time	2 ms
Release Time	1 ms
Temperature Range - Operating	-40°C ~ 85°C
Contact Material	Silver Alloy, Gold Alloy
Relay Type	General Purpose
Coil Resistance	1.44 kOhms
Standard Package	35 pcs
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.41.0020
Win Source Part Number	587904-EC2-12SNU
Ultra Librarian 3D Model	Ultra Librarian EC2-12SNU CAD Model

Alternative Products

Description

The EC2-12SNU is a DPDT (2 Form C) latching relay from KEMET's EC2 series.

Manufacturer: KEMET
Series: EC2
Type: DPDT (2 Form C) Latching Relay
Coil Voltage: 12VDC
Coil Resistance: 1.44 kOhms
Contact Material: Silver alloy and gold alloy
Contact Rating: 2A
Switching Voltage (VAC): Up to 250VAC
Switching Voltage (VDC): Up to 220VDC
Operate Time: 2ms
Release Time: 1ms
Application: General-purpose
Mounting Type: Through-hole
Operating Temperature: -40°C to 85°C
Package: Tube
Standard Package: 35 pcs
