Same model may have multiple batches, images only for reference.

EE2-5NUH

Name: EE2-5NUH
Brand: Kemet
SKU: 844650
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	EE2-5NUH
Manufacturer	Kemet
Catalog	Signal Relays, Up to 2 Amps
Description	RELAY GEN PURPOSE DPDT 2A 5VDC / General Purpose Relay DPDT (2 Form C) Surface Mount
Datasheet	EE2-5NUH Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Relays - Signal Relays, Up to 2 Amps
Mfr	KEMET
Series	EE2
Package	Tube
Product Status	Active
Mounting Type	Surface Mount
Coil Voltage	5VDC
Contact Form	DPDT (2 Form C)
Contact Rating (Current)	2 A
Switching Voltage	250VAC, 220VDC - Max
Coil Current	28 mA
Coil Type	Non Latching
Termination Style	Gull Wing
Must Operate Voltage	3.75 VDC
Must Release Voltage	0.5 VDC
Operate Time	2 ms
Release Time	1 ms
Temperature Range - Operating	-40°C ~ 85°C
Contact Material	Silver Alloy, Gold Alloy
Relay Type	General Purpose
Coil Resistance	178 Ohms
Standard Package	3,360 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.41.0020
Win Source Part Number	844650-EE2-5NUH
Ultra Librarian 3D Model	Ultra Librarian EE2-5NUH CAD Model

Alternative Products

Description

The EE2 series relay is a high-quality signal relay designed for various applications in the electronics industry.

Contact Form: DPDT (2 Form C)
Contact Material: Silver Alloy and Gold Alloy
Coil Voltage: 5VDC
Coil Resistance: 178 Ohms
Coil Current: 28 mA
Switching Voltage: 250VAC and 220VDC Maximum
Operate Time: 2 ms
Release Time: 1 ms
Temperature Range: -40°C to 85°C
Mounting Type: Surface Mountable
Type: General-Purpose Relay
