Same model may have multiple batches, images only for reference.
MPXV1D1770L2R2 Kemet
Same model may have multiple batches, images only for reference.

MPXV1D1770L2R2

Part No MPXV1D1770L2R2
Manufacturer Kemet
Catalog Fixed Inductors
Description FIXED IND 2.2UH 31A 2.6 MOHM SMD / 2.2 µH Shielded Inductor 31 A 2.6mOhm Max Nonstandard
Datasheet
MPXV1D1770L2R2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr KEMET
Series MPXV
Package Tape & Reel
Product Status Active
Type -
Material - Core Metal Composite
Inductance 2.2 µH
Tolerance ±20%
Current Rating (Amps) 31 A
Current - Saturation (Isat) 34A
Shielding Shielded
DC Resistance (DCR) 2.6mOhm Max
Q @ Freq -
Frequency - Self Resonant 15MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 155°C
Inductance Frequency - Test 100 kHz
Features -
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.669" L x 0.673" W (17.00mm x 17.10mm)
Height - Seated (Max) 0.276" (7.00mm)
Base Product Number MPXV1D1770
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1352381-MPXV1D1770L2R2
Ultra Librarian 3D Model Ultra Librarian MPXV1D1770L2R2 CAD Model

Description

The KEMET MPXV1D1770L2R2 is a fixed inductor with an inductance of 2.2 µH and a current rating of 31 A.

  • Inductance: 2.2 µH
  • Current Rating: 31 A
  • Tolerance: ±20%
  • Series: MPXV
  • Mounting Type: Surface Mount
  • Package Size: Nonstandard
  • Dimensions: 0.669" L x 0.673" W (17.00mm x 17.10mm)
  • Seated Height: 0.276" (7.00mm)
  • Shielded: Yes
  • DC Resistance (DCR): 2.6mOhm max
  • Frequency Range: 15MHz
  • Temperature Range: -55°C to 155°C
