Same model may have multiple batches, images only for reference.

SHBC8S-0R6A0043V

Name: SHBC8S-0R6A0043V
Brand: Kemet
SKU: 1272739
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	SHBC8S-0R6A0043V
Manufacturer	Kemet
Catalog	Fixed Inductors
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	KEMET
Series	SHBC
Package	Bulk
Type	Toroidal
Material - Core	Alloy Powder
Inductance	43 µH
Tolerance	±20%
Current Rating (Amps)	2 A
Shielding	Unshielded
DC Resistance (DCR)	54.1mOhm Max
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting Type	Through Hole
Package / Case	Radial, Vertical (Open)
Supplier Device Package	Radial
Dimension	0.669" Dia (17.00mm)
Height - Seated (Max)	0.669" (17.00mm)
Base Product Number	SHBC8S
Other Names	399-19132,UALS8S0R6A0043
Standard Package	700
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1272739-SHBC8S-0R6A0043V
Ultra Librarian 3D Model	Ultra Librarian SHBC8S-0R6A0043V CAD Model

Alternative Products

Description

The SHBC series inductors are toroidal inductors with an unshielded package.

Standard Package: 700
DC Resistance: 54.1mOhm max
Inductance: 43 µH
Tolerance: ±20%
Core Material: Alloy powder
Temperature Range: -40°C to 125°C
Height: 0.669" (17.00mm)
Diameter: 0.669" (17.00mm)
Current Rating: 2 A
Inductance Frequency Test: 100 kHz
