GAL16V8D-15LP Real Image GAL16V8D-15LP Real Image
Same model may have multiple batches, images only for reference.
GAL16V8D-15LP Real Image GAL16V8D-15LP Real Image
GAL16V8D-15LP Real Image GAL16V8D-15LP Real Image
Same model may have multiple batches, images only for reference.

GAL16V8D-15LP

Part No GAL16V8D-15LP
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description High Performance E2CMOS PLD Generic Array Logic | IC CPLD 8MC 15NS 20DIP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete
Programmable Type EE PLD
Delay Time tpd(1) Max 15.0ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 8
Temperature Range - Operating 0°C ~ 75°C
Mounting Style Through Hole
Manufacturer Package 20-DIP
Supplier Device Package 20-PDIP
Family Part Number GAL16V8
Manufacturer Pack Quantity 360
MSL Level 3 (168 Hours)
Win Source Part Number 1176777-GAL16V8D-15LP
Manufacturer Homepage www.latticesemi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL16V8D-15LP CAD Model

Description

The GAL16V8D-15LP is an EE PLD integrated circuit from Lattice Semiconductor Corporation.

  • Maximum Delay Time: 15.0ns
  • Voltage Supply Range: 4.75V to 5.25V
  • Macrocells: 8
  • Package: 20-PDIP
  • Status: Obsolete
  • Alternative Cross-References: GAL16V8D-15LPN, GAL16V8B-15LP, and GAL16V8D-15LS
  • Popularity: Medium
  • Supply and Demand Status: Balanced
