The GAL16V8D-25LJNI is a high-performance, low-power Generic Array Logic (GAL) device manufactured by Lattice Semiconductor Corporation. It is an electrically erasable programmable logic device (EEPLD) that can be configured to implement a wide variety of custom logic functions.

Applications

• Address decoding
• Glue logic
• State machine implementation
• Peripheral control
• Timing control

Features

• Electrically erasable programmable logic
• High-performance operation
• Low-power consumption
• Reconfigurable logic
• 25 ns propagation delay
• Eight output logic macrocells (OLMCs)
• 16 input pins

Benefits

• Provides a flexible and customizable logic solution
• Reduces component count and board space
• Simplifies circuit design
• Offers fast performance
• Conserves power
• Allows for easy design changes

Additional Details

The GAL16V8D-25LJNI is a versatile programmable logic device that can be used to implement a wide range of custom logic functions. It features eight output logic macrocells (OLMCs), each of which can be configured as an output, input, or bidirectional pin. The device has 16 input pins, providing ample connectivity for complex logic functions. The GAL16V8D-25LJNI offers a fast propagation delay of 25 ns, enabling high-performance operation. It is electrically erasable, allowing for easy reprogramming and design changes. The device is available in a variety of packages, including DIP and SOIC. Detailed information regarding the programming procedure and the specific configuration options for the OLMCs can be found in the device datasheet. It is typically programmed using specialized programming software and hardware tools compatible with Lattice Semiconductor devices. It operates on a 5V power supply.
