Overview

The OR2C04A2J160-DB is a Field-Programmable Gate Array (FPGA) from Lattice Semiconductor Corporation's ORCA 2C series. It is designed to provide a flexible and cost-effective solution for implementing custom digital logic circuits. This FPGA offers a combination of programmable logic blocks, routing resources, and I/O capabilities, making it suitable for a variety of applications. The OR2C04A2J160-DB is commonly used in telecommunications, networking, industrial control, and other embedded systems where programmability and quick turnaround times are essential.

Applications

• Telecommunications
• Networking Equipment
• Industrial Control Systems
• Embedded Systems
• Data Acquisition

Features

• Programmable Logic: Offers a configurable array of logic blocks for implementing custom digital circuits.
• Flexible Routing: Provides a hierarchical routing architecture for connecting logic blocks and I/O pins.
• On-Chip Memory: Includes embedded memory blocks for data storage and processing.
• I/O Versatility: Supports a wide range of I/O standards and voltages.
• JTAG Configuration: Allows for easy programming and debugging via JTAG interface.

Benefits

• Design Flexibility: Enables customization and reconfiguration of hardware to meet specific application needs.
• Reduced Time-to-Market: Allows for rapid prototyping and development, shortening the design cycle.
• Cost-Effectiveness: Offers a cost-optimized solution compared to custom ASIC designs.
• Easy Programming: Supported by Lattice's design software and JTAG configuration.
• Adaptability: Allows for design changes and updates without requiring hardware modifications.

Additional Details

The OR2C04A2J160-DB comes in a J160 package. The 'DB' suffix may indicate a specific die revision or manufacturing variation. It requires a power supply voltage typically in the range of 3.3V or 5V, depending on the specific configuration and I/O requirements. The FPGA is typically configured using a JTAG programmer and Lattice's development tools. Detailed specifications such as the number of logic cells, memory size, and I/O pin count can be found in the manufacturer's datasheet. The OR2C04A2J160-DB is a suitable choice for designs that require flexibility, programmability, and quick turnaround times.
