Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 1.5V
Output Current 15A
Voltage - Input 4.5 V ~ 14 V
Regulator Topology Buck
Frequency - Switching 400kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LTC3851
Win Source Part Number 783722-DC1171A-B
Popularity Medium
Supply and Demand Status Balance
Introduction Date September 02, 2008
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC1171A-B CAD Model

Description

Product Overview: DC1171A-B

The DC1171A-B is a high-performance demonstration board from Linear Technology, designed to showcase the capabilities of the LTC6803 Multicell Battery Stack Monitor. This product is an essential tool for engineers and designers working on energy storage and management systems, particularly those found in electric vehicles, grid storage, and backup power systems.

Key Features

  • Integrated Battery Monitoring: The LTC6803 chip integrated into the DC1171A-B can monitor up to 12 individual battery cells in a series stack, ensuring all cells are operating within their safe voltage range.
  • High Voltage Capability: The board is capable of handling a total stack voltage of up to 60V, making it suitable for many high-voltage applications.
  • Precision Voltage Measurement: The LTC6803 provides high-accuracy voltage measurement, crucial for the precise balancing and management of battery cells.
  • Robust Communication: It includes an isolated SPI interface for robust communication with a host controller, even in noisy environments.
  • Temperature Monitoring: The demonstration board also allows for temperature monitoring, which is critical for the safety and longevity of battery cells.
  • Compact Design: The DC1171A-B is designed to be compact and efficient, making it easy to integrate into existing systems without significant modifications.

Applications

The DC1171A-B is intended for use in a variety of applications where battery health and performance are critical. These include:

  • Electric and Hybrid Electric Vehicles (EV/HEV)
  • Energy Storage Systems (ESS)
  • Backup Power Systems
  • Uninterruptible Power Supplies (UPS)

Technical Support and Resources

Linear Technology provides extensive technical support for the DC1171A-B. Users can access a wealth of resources, including datasheets, application notes, and design simulation tools, to aid in the integration and use of the product. Furthermore, Linear Technology's technical support team is available to assist with any questions or challenges that may arise during the design process.
