Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose DC/DC, Step Up
Outputs and Type 2, Non-Isolated
Voltage - Output 15V, -8V
Output Current 65mA, 45mA
Voltage - Input 2.7 V ~ 4.2 V
Regulator Topology Boost, Inverting
Frequency - Switching 1.1MHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LT3472
Win Source Part Number 781031-DC760A
Popularity Medium
Supply and Demand Status Balance
Family Name DC760A
Introduction Date September 17, 2004
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC760A CAD Model

Description

The Linear Technology DC760A is a high-performance evaluation board designed for testing and prototyping with Linear Technology's LTC3566, a multifunction power management solution for portable applications. The DC760A stands out due to its versatility and efficiency, making it an ideal platform for developers and engineers looking to explore the capabilities of the LTC3566 chip.

Key Features:

  • Integrated Power Management: The LTC3566 integrates multiple power management functions including a USB-compatible linear charger, a PowerPath™ manager, an ideal diode, overvoltage protection, as well as a synchronous buck-boost DC/DC converter.
  • USB On-The-Go (OTG) Support: The board facilitates USB OTG applications by providing a seamless power flow between the input supply, battery, and load, ensuring reliable operation even when the input supply is limited or fluctuating.
  • High-Efficiency Conversion: The synchronous buck-boost converter is capable of high-efficiency operation over a wide range of battery voltages, which is critical for maximizing battery life in portable devices.
  • Programmable Charge Rate: The LTC3566 allows for programmable charge rates, enabling users to customize the charging profile to suit various battery chemistries and capacities.
  • Compact Design: The DC760A evaluation board is designed with a compact form factor, making it easy to integrate into a variety of design prototypes without significant space constraints.

Applications:

The DC760A is suitable for a broad range of applications, particularly where efficient power management and battery charging are critical. This includes handheld devices, portable media players, digital cameras, and other USB-based consumer electronics that require reliable power management.

Easy to Use:

The evaluation board comes with comprehensive documentation, including schematics, layout files, and application notes, which help to streamline the development process. Furthermore, the DC760A is compatible with Linear Technology's QuikEval™ system, allowing for easy connection to a PC for data acquisition and analysis.

By leveraging the DC760A evaluation board, developers can significantly reduce their time-to-market with a well-tested platform that demonstrates the full capabilities of the LTC3566, all while ensuring optimal power efficiency and functionality in their final product designs.
