Linear Technology's DC782A-K - High-Performance Data Converter
The DC782A-K from Linear Technology is a state-of-the-art data converter demonstration board that showcases the capabilities of the LTC2380-24, a 24-bit, 2Msps ADC (Analog to Digital Converter). This product is designed for engineers and developers who require high precision and speed in their applications such as medical imaging, test equipment, and high-speed data acquisition systems.
Key Features
- High Precision: With 24-bit resolution, the LTC2380-24 provides exceptional accuracy and noise performance, making it suitable for the most demanding measurement tasks.
- Fast Sampling Rate: The ability to sample at rates up to 2Msps allows for high-speed signal processing, which is critical in applications where timing and throughput are crucial.
- No Latency Operation: The LTC2380-24 features no pipeline delay, which is essential for real-time control and monitoring applications.
- Easy Integration: The DC782A-K demo board connects to a DC890B USB data collection board, allowing for easy interface with a PC for data analysis and visualization.
- Software Support: The board is supported by Linear Technology's QuikEval™ software, which provides a user-friendly graphical interface for data collection and analysis.
Applications
The DC782A-K is versatile and can be used in a wide range of applications, including:
- Medical Imaging Systems
- High-Speed Data Acquisition
- Instrumentation
- Seismic Data Analysis
- Industrial Process Control
Technical Specifications
Parameter
Specification
Resolution
24-Bit
Sampling Rate
Up to 2Msps
Interface
USB (via DC890B)
Software
QuikEval™
The DC782A-K is a demonstration kit that exemplifies the performance and ease of use expected from Linear Technology's high-end data converters. With its advanced features and comprehensive software support, it is an ideal solution for professionals seeking precision and speed in their electronic designs.
