Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Part Status Active
Number of A/D Converters 1
Number of Bits 16
Sampling Rate (Per Second) 250k
Data Interface Parallel
Input Range ±10 V
Power (Typ) @ Conditions 75mW @ 250kSPS
Utilized IC / Part LTC1606
Supplied Contents Board(s)
Win Source Part Number DC1255A-B-106553
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DC1255A-B CAD Model

Description

Overview of Product DC1255A-B

Linear Technology's DC1255A-B is a high-performance demonstration board designed for evaluating the capabilities of the LTC3880EUJ, a dual-output, high-efficiency, synchronous step-down DC/DC controller with I²C-based PMBus interface. This advanced controller integrates digital power system management, allowing for precise control and monitoring of power supply parameters.

Key Features of DC1255A-B

  • Intelligent Power System Management: The LTC3880EUJ controller features an I²C/PMBus interface for advanced system control, telemetry, and monitoring, providing real-time insight into the power system’s performance.
  • Efficient Power Conversion: The demonstration board showcases the LTC3880EUJ's ability to drive synchronous step-down power stages, delivering high efficiency and fast transient response for critical applications.
  • Dual Output Channels: With two independently regulated outputs, the DC1255A-B can supply different voltage levels, which can be adjusted and configured via the PMBus interface, making it flexible for various applications.
  • Robust Design: The board is engineered to handle a wide input voltage range, providing a stable and reliable power solution that is suitable for many industrial, automotive, and communication applications.
  • Comprehensive Protection Features: The LTC3880EUJ includes overvoltage, undervoltage, overcurrent, and overtemperature protection to ensure the longevity and safety of the power system.

Applications

The DC1255A-B demonstration board is ideal for a multitude of applications, including:

  • Datacom and Telecom Systems
  • Industrial Equipment
  • Automotive Electronics
  • Enterprise Computing
  • High-Density Distributed Power Systems

Easy Integration and User-Friendly Interface

The DC1255A-B comes with user-friendly software that facilitates easy integration into existing systems. Through this software, engineers can access a range of configuration settings and monitoring tools, ensuring the power supply operates optimally for the specific needs of the application.

In summary, the DC1255A-B from Linear Technology is an exemplary solution for anyone looking to implement a sophisticated, digitally-controlled power system that demands precision, efficiency, and reliability.
