Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Number of Converters 1
Resolution 14
Sampling Rate 65M
Data Interface Parallel
Input Range 1.5 ~ 2.25 Vpp
Power (Typ) @ Conditions 597mW @ 65MSPS
Utilized IC / Part LTC2205-14
Supplied Contents Board(s)
Win Source Part Number 782412-DC919A-I
Popularity Medium
Supply and Demand Status Balance
Family Name DC919A
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC919A-I CAD Model

Description

The Linear Technology DC919A-I is a high-precision data converter module designed to provide exceptional accuracy and performance for demanding applications. This product is a testament to Linear Technology's commitment to providing innovative solutions for complex data conversion challenges.

Key Features

  • High Resolution: The DC919A-I boasts a high-resolution ADC (Analog-to-Digital Converter), enabling it to handle intricate signal conversion with precision, making it ideal for applications that require detailed data analysis.
  • Fast Sampling Rate: With a rapid sampling rate, this data converter can process high-frequency signals without compromising the integrity of the data, ensuring real-time performance for time-sensitive tasks.
  • Low Noise Design: Engineered to minimize noise interference, the DC919A-I ensures that the data captured is as accurate and clean as possible, which is critical for high-stakes measurements and analyses.
  • Easy Integration: The module is designed for easy integration into existing systems, providing a seamless upgrade path for enhancing data conversion capabilities without extensive modifications.

Applications

The DC919A-I is versatile and can be utilized across a wide range of applications, including:

  • Medical Imaging
  • Instrumentation
  • Communications Systems
  • Industrial Automation
  • High-end Audio Equipment

Technical Specifications

Parameter Specification Resolution High-Resolution ADC Sampling Rate Fast Noise Low Noise Circuitry Integration User-Friendly

Whether you are developing cutting-edge technology or upgrading existing systems, the Linear Technology DC919A-I data converter is designed to meet the rigorous standards of modern electronics, providing reliable, high-fidelity data conversion for your most critical applications.
