Products specifications

Category Integrated Circuits (ICs) - Interface - Drivers, Receivers, Transceivers
Mfr Linear Technology
Series *
Package Bulk
Product Status Active
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) Vendor Undefined
REACH Status REACH Affected
Win Source Part Number 622601-LT1180ACSW
Ultra Librarian 3D Model Ultra Librarian LT1180ACSW CAD Model

Description

Introducing the LT1180ACSW from Linear Technology

The LT1180ACSW is a remarkable low-power 5V RS232 dual driver/receiver that includes two drivers and two receivers, designed to meet the requirements of the RS232 and V.28 standards while operating from a single 5V power supply. This high-performance component is a part of Linear Technology's range of interface ICs, which are renowned for their reliability and efficiency in communication applications.

One of the standout features of the LT1180ACSW is its low power consumption, making it an ideal choice for battery-powered and portable applications. It operates with a supply current as low as 500µA, ensuring minimal impact on your system's power budget. Additionally, the device is capable of functioning at data rates up to 120kbps, providing the speed necessary for a wide array of data communication tasks.

The LT1180ACSW includes an automatic power-down feature that reduces the supply current to 1µA when the device is not transmitting or receiving data, further enhancing its power efficiency. This feature is particularly useful in battery-operated systems where power conservation is critical.

The robust design of the LT1180ACSW ensures that the device can withstand ±10V input levels without damage, making it resilient in harsh electrical environments. Moreover, the drivers maintain ±5V output swing under full load, which is compliant with the RS232 specification, ensuring reliable data transmission even over long cable runs.

For ease of integration, the LT1180ACSW is available in a 16-pin narrow SO package, and it is designed to be compatible with the industry-standard footprint. This makes the device a straightforward drop-in replacement for many existing designs, simplifying the upgrade process and reducing time to market for new products.

In summary, the LT1180ACSW from Linear Technology is an exceptional choice for designers seeking a low-power, reliable, and efficient RS232 interface solution. Its combination of low power consumption, high data rate capability, automatic power-down feature, and robustness against input overvoltages makes it a versatile component for a wide range of communication applications.
