LT1461DHS8-5 Precision Voltage Reference

The LT1461DHS8-5 is a high-precision voltage reference component manufactured by Linear Technology, which is renowned for its stability and accuracy. This particular model is part of the LT1461 series, offering a fixed output voltage of 5V. Designed to maintain consistent performance over a wide range of operating conditions, the LT1461DHS8-5 is an ideal choice for high-end applications requiring a stable voltage reference.

Key Features:

• High Accuracy: The LT1461DHS8-5 boasts an impressive initial accuracy of ±0.05%, ensuring precise voltage regulation for sensitive electronic circuits.
• Low Temperature Coefficient: With a temperature coefficient of only 10ppm/°C, the device promises excellent stability across temperature variations, making it suitable for both commercial and industrial environments.
• Low Dropout Voltage: The component requires a minimal difference between the input and output voltages, facilitating efficient operation even in low headroom applications.
• Low Output Noise: It exhibits a low noise characteristic of 20µVrms over a 10Hz to 10kHz bandwidth, contributing to the overall noise reduction in sensitive electronic systems.
• Long-Term Stability: The LT1461DHS8-5 offers long-term stability as low as 30ppm/1000 hours at 125°C, ensuring reliable performance over the product's lifespan.
• Wide Operating Range: This voltage reference can operate across a broad input voltage range from 7V to 30V, providing versatility in various power supply configurations.

Applications:

The LT1461DHS8-5 is used in a diverse array of applications that require high precision and stability in voltage reference. These include:

• Precision data converters (ADCs/DACs)
• High-resolution analog-to-digital conversion systems
• Portable instrumentation
• Industrial process control systems
• Automotive electronics
• Medical equipment

With its robust package, the LT1461DHS8-5 is encapsulated in an 8-lead SOIC package, providing a compact solution that is both durable and easy to integrate into a wide range of electronic assemblies. Whether for test equipment, high-precision instrumentation, or any application where voltage accuracy is paramount, the LT1461DHS8-5 from Linear Technology stands as a reliable and high-performance choice.
