Product Overview: LT1764AEQ-3.3#TR

The LT1764AEQ-3.3#TR, from Linear Technology, is a high-performance, low dropout (LDO) linear regulator that offers exceptional output voltage accuracy and stability. This regulator is designed to provide a fixed output voltage of 3.3V, which is a common requirement for many digital and analog circuits. The device is part of the LT1764A series, renowned for its low noise characteristics and fast transient response.

Key Features

• Low Dropout Voltage: The LT1764AEQ-3.3#TR has an extremely low dropout voltage, which means it can regulate output voltage effectively even when the input-to-output voltage differential is minimal. This feature is particularly useful in battery-powered applications where maximizing the utilization of the available input voltage is crucial.
• High Output Current: This regulator can deliver up to 3A of continuous output current, making it suitable for high-power applications.
• Stable with Low ESR Output Capacitors: The device is stable with ceramic capacitors, which have lower equivalent series resistance (ESR) than traditional tantalum or aluminum electrolytic capacitors. This enables the use of smaller, more reliable, and less expensive capacitors.
• Excellent Transient Response: The LT1764AEQ-3.3#TR offers a fast transient response, which is essential for applications where the load conditions change rapidly, such as microprocessors and digital signal processors.
• Low Noise: With its optimized design, the regulator inherently generates low noise without the need for additional noise reduction components.
• Over-temperature and Over-current Protection: Built-in thermal and current limit protection features safeguard the device and the application against fault conditions.

Applications

The LT1764AEQ-3.3#TR is well-suited for a variety of applications, including but not limited to:

• Power supplies for DSPs and microcontrollers
• High-efficiency linear power regulators
• Post-regulation for switching supplies
• Battery-powered equipment
• Peripheral power supplies

Product Packaging and Quality

This LDO comes in a compact 5-lead TO-263 package, which is designed for surface-mount technology (SMT) and is suitable for high-volume production. The part number suffix "TR" indicates that the product is provided in tape and reel packaging, which facilitates automated pick-and-place assembly processes. Linear Technology ensures high-quality standards, and the LT1764AEQ-3.3#TR is no exception, providing reliable performance for critical applications.
