Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Amplifier Type Current Sense
Number of Circuits 1
Voltage - Input Offset 40μV
Operating Supply Current 60μA
Channel Output Current 50μA
Supply Voltage - Operating 2.5 V to 36 V, ±1.25 V to 18 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-MSOP
Win Source Part Number 1058718-LT1787CMS8#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT1787CMS8#TRPBF CAD Model

Description

Linear Technology's LT1787CMS8#TRPBF High Side Current Sense Amplifier

The LT1787CMS8#TRPBF is a precision, high-side current sense amplifier designed by Linear Technology, now part of Analog Devices, to cater to a broad spectrum of applications requiring accurate current monitoring. This device is encapsulated in a compact MSOP-8 package, which is ideal for space-constrained applications.

Key Features:

  • High-Side Current Sensing: The LT1787 is capable of sensing the current on the high side of the load, which allows for ground-referenced loads and eliminates the need for a ground lift.
  • Wide Input Common Mode Range: This amplifier operates with a common mode voltage range from 4V to 60V, making it suitable for a variety of systems, including those with higher supply voltages.
  • Low Current Consumption: With a quiescent current of just 60μA (typical), the LT1787 is an excellent choice for power-sensitive applications.
  • High Accuracy: The device offers excellent accuracy with a maximum input offset voltage of 500μV, ensuring reliable current measurement across its operating range.
  • Wide Operating Temperature Range: The LT1787CMS8#TRPBF is designed to function over an industrial temperature range from -40°C to 85°C, assuring performance in harsh environments.

Applications:

The versatility of the LT1787CMS8#TRPBF makes it a perfect fit for various applications, including but not limited to:

  • Battery Management
  • Power Management
  • Portable Devices
  • Automotive Systems
  • Telecommunication Infrastructure
  • Industrial Controls

Product Advantages:

The LT1787CMS8#TRPBF stands out in the market with its ability to combine high accuracy, low power consumption, and the convenience of high-side current sensing. Its robust design allows it to withstand transient events and operate reliably in a wide range of conditions. Moreover, the MSOP-8 packaging is not only space-efficient but also offers a thermal advantage for better power handling capability.

In conclusion, Linear Technology's LT1787CMS8#TRPBF is an exemplary solution for designers looking to implement precise current sensing in their systems without compromising on space or power efficiency. Its robustness and versatility make it an essential component in a multitude of electronic applications.
