Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, Cuk, Flyback, SEPIC
Output Type Adjustable
Number of Outputs 2
Minimum Input Voltage 2.4V
Maximum Input Voltage 16V
Nominal Output Voltage (Min/Fixed) ±1V
Maximum Output Voltage ±40V
Output Current 1.3A
Frequency - Switching 1.2MHz
Synchronous Rectifier No
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 118485-LT3471EDD#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name LT3471
Introduction Date October 08, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT3471EDD#TRPBF CAD Model

Description

The LT3471EDD#TRPBF is a versatile dual channel, 1.2A, 1.3MHz step-up DC/DC converter from Linear Technology, designed to meet the rigorous demands of modern compact electronic devices. This high-performance converter is housed in a small 10-lead DFN package, making it an ideal solution for space-constrained applications.

Key Features:

  • Wide Input Voltage Range: Capable of operating from an input voltage range of 2.5V to 16V, the LT3471EDD#TRPBF is suitable for a variety of power sources, including single-cell Li-Ion batteries.
  • High Switching Frequency: Its 1.3MHz fixed frequency operation allows for the use of small, low-cost inductors and capacitors, leading to a compact and efficient design.
  • Dual Independent Outputs: The device features two independent output channels, each capable of delivering up to 1.2A of continuous output current, making it perfect for applications that require multiple regulated voltages.
  • Adjustable Output Voltage: Output voltages are adjustable up to 38V, providing flexibility for a wide range of applications.
  • Inbuilt Soft-Start Function: The soft-start function limits inrush current during startup, enhancing the reliability of the device.
  • Thermal Protection: Integrated thermal shutdown provides protection against overheating, ensuring the longevity of the converter.
  • Low Shutdown Current: The shutdown current is less than 1µA, which enhances the power efficiency, especially in battery-powered systems.

Applications:

  • Portable Electronics
  • Power LED Drivers
  • Battery-Powered Equipment
  • Industrial Power Supplies
  • Local Power Distribution Systems

The LT3471EDD#TRPBF is a powerful and efficient solution for designers looking to implement a dual-channel power supply in their systems. Its high-frequency operation, combined with the ability to drive high currents and adjust to a wide range of output voltages, make it a highly versatile component suitable for a multitude of electronic applications.
