Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology/Analog Devices
Part Status Last Time Buy
Function Step-Up, Step-Up/Step-Down
Output Configuration Positive and Negative (Dual Rail)
Topology Boost, Cuk, Flyback, SEPIC
Output Type Adjustable
Number of Outputs 2
Voltage - Input (Minimum) 2.1V
Voltage - Input (Maximum) 16V
Min/Fixed Output Voltage ±1V
Maximum Output Voltage ±40V
Output Current 1.3A
Switching Frequency 1.2MHz
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 10-WFDFN Exposed Pad
Supplier Device Package 10-DFN (3x3)
Manufacturer Pack Quantity 121
MSL Level 1 (Unlimited)
Win Source Part Number 1206696-LT3471EDD
Manufacturer Homepage www.linear.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name LT3471
Introduction Date August 30, 2004
ECCN EAR99
Country of Origin Malaysia ,Thailand
Halogen Free Compliant
Ultra Librarian 3D Model Ultra Librarian LT3471EDD CAD Model

Description

Linear Technology's LT3471EDD: A Compact, Dual Channel, 1.2A Step-Up DC/DC Converter

The LT3471EDD is a versatile and powerful DC/DC converter from Linear Technology, now part of Analog Devices, designed to cater to a broad range of applications requiring efficient power conversion. This dual-channel, step-up converter is capable of generating two high voltage outputs up to 42V from an input voltage range of 2.5V to 16V, making it an ideal choice for battery-powered devices, automotive applications, and industrial systems.

One of the standout features of the LT3471EDD is its internal 1.2A, 42V switches which allow for a compact design with minimal external components. The device is housed in a small 10-lead DFN package, offering a space-saving solution for designs where PCB real estate is at a premium. Despite its small size, the LT3471EDD does not compromise on performance, delivering high efficiency and low quiescent current, which is crucial for maximizing battery life in portable applications.

The LT3471EDD boasts integrated soft-start functionality, which limits inrush current during startup, thereby reducing stress on the input power source. It also features a unique switching architecture that ensures both channels can operate independently, even when delivering high output voltages, without the need for a coupled inductor or complex transformers. This simplifies the design and reduces overall system cost.

With its wide input voltage range and adjustable switching frequency from 1.2MHz to 2.8MHz, the LT3471EDD provides designers with flexibility to optimize the converter for size, efficiency, or required output power. Additionally, the switching frequency can be synchronized to an external clock, allowing for noise-sensitive applications to avoid critical frequency bands.

Protection features of the LT3471EDD include thermal shutdown, a current limit, and frequency foldback that helps protect the device under short-circuit conditions. These safety measures ensure reliable operation under a variety of conditions, contributing to the longevity of the end product.

In summary, the LT3471EDD from Linear Technology is a highly integrated, dual-channel step-up DC/DC converter that offers a compact solution without sacrificing performance or features. Its versatility and robustness make it suitable for a wide array of applications that demand reliable and efficient power conversion.
