Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 3.6V
Maximum Input Voltage 36V
Nominal Output Voltage (Min/Fixed) 0.79V
Maximum Output Voltage 20V
Output Current 2A
Frequency - Switching 200kHz to 2.4MHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 1059331-LT3480IDD#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT3480IDD#TRPBF CAD Model

Description

Product Overview: LT3480IDD#TRPBF

The LT3480IDD#TRPBF is a high-performance, step-down switching regulator from Linear Technology, designed to deliver efficient power management and conversion for a wide range of applications. This compact and versatile component is ideal for portable devices, industrial controls, and automotive systems, where reliable and efficient voltage regulation is critical.

Key Features

  • Wide Input Voltage Range: The LT3480IDD#TRPBF operates from a 4V to 36V input voltage range, making it suitable for applications with varying power supplies, including automotive and industrial environments.
  • Adjustable Output Voltage: Users can set the output voltage from 1.22V to 34V, which allows for flexibility in different circuit designs and the ability to cater to specific voltage requirements of different loads.
  • High Efficiency: With a switching frequency up to 2.2MHz, the device can utilize small inductors and capacitors, resulting in a compact power supply design with good power efficiency.
  • Low Dropout Operation: The LT3480IDD#TRPBF's low dropout performance ensures efficient operation even when the input voltage is close to the output voltage, enhancing the battery life of portable devices.
  • Robust Thermal Performance: The component is available in a thermally efficient 10-lead MSOP package with exposed pad for enhanced thermal dissipation.

Protection Features

  • Built-in Protection: The device includes over-temperature protection, over-current protection, and a power good flag that ensures safe operation under abnormal conditions.
  • Stable Operation: The LT3480IDD#TRPBF is designed with internal compensation to minimize external parts and ensure stable operation throughout the entire range of input and output voltages.

Applications

  • Automotive Electronics
  • Portable Devices
  • Industrial Controls
  • Power Supplies
  • Distributed Power Systems

The LT3480IDD#TRPBF by Linear Technology is a reliable and flexible solution for designers looking for a high-efficiency, adjustable step-down regulator capable of withstanding the rigors of demanding applications.
