Introducing the LT3504EUFD#TRPBF from Linear Technology

Linear Technology presents the LT3504EUFD#TRPBF, a versatile and robust quad-channel, current mode PWM step-down DC/DC converter designed to cater to a wide array of power supply requirements. This high-performance product is an ideal solution for applications requiring multiple output voltages in a compact form factor.

Key Features

• Wide Input Voltage Range: The LT3504EUFD#TRPBF operates efficiently with an input voltage range from 3.0V to 36V, making it suitable for applications that experience wide input voltage variations.
• Independent Channels: Each of the four channels is independent with its own 1.1A internal power switch, allowing for flexible design configurations and the ability to power multiple loads simultaneously.
• Adjustable Switching Frequency: The device offers an adjustable switching frequency from 250kHz to 2.2MHz, which can be synchronized to an external clock to minimize electromagnetic interference (EMI) or optimized for efficiency.
• Robust Thermal Performance: Housed in a 4mm x 5mm QFN package, the LT3504EUFD#TRPBF features excellent thermal performance, ensuring reliable operation even in demanding environments.
• Additional Protection Features: It includes over-temperature protection, short-circuit protection, and cycle-by-cycle current limit, providing a safeguard for your system under abnormal conditions.

Applications

The LT3504EUFD#TRPBF is highly adaptable and can be used in various applications, such as:

• Automotive and Industrial Supplies
• Distributed Power Systems
• Battery-Powered Equipment
• Point of Load Power Supplies

Quality and Reliability

Linear Technology is known for its commitment to quality, and the LT3504EUFD#TRPBF is no exception. It is designed to meet the stringent requirements of even the most critical applications. With its robust design and comprehensive protection features, you can rely on this converter to provide consistent performance and longevity.

In summary, the LT3504EUFD#TRPBF by Linear Technology is a highly integrated, efficient, and reliable solution for your multi-channel power supply needs. Whether you're designing for the automotive industry, creating portable devices, or building industrial power systems, this converter is engineered to help you achieve a superior performance-to-size ratio while ensuring the safety and stability of your application.
