The LT3509IMSE#TRPBF is a high-performance, dual-channel, current mode PWM step-down DC/DC converter manufactured by Linear Technology. It is designed to operate over a wide input voltage range, making it suitable for a variety of applications including automotive, industrial, and telecommunications power systems. This versatile component delivers efficient power conversion with minimal external components, ensuring a compact and reliable power solution.

Key Features

• Wide Input Voltage Range: The LT3509IMSE#TRPBF operates from an input voltage range of 3V to 36V, accommodating a broad spectrum of power sources.
• Dual Independent Channels: It offers two independent output channels, each capable of driving a 1.4A load with excellent line and load regulation.
• Adjustable Switching Frequency: Users can set the switching frequency anywhere from 330kHz to 2.5MHz, allowing for flexibility in design and optimization of inductor size and efficiency.
• Robust Thermal Performance: The device is housed in an MSOP-16E package, which provides enhanced thermal performance and space-saving on the PCB.
• No Current Sense Resistor Required: The LT3509IMSE#TRPBF utilizes internal top-side power switches with current sensing, eliminating the need for an external sense resistor and simplifying the design.

Applications

The LT3509IMSE#TRPBF is ideal for a range of applications, such as:

• Automotive power systems
• Portable instruments
• Industrial power supplies
• Distributed DC/DC systems
• Telecommunications equipment

Quality and Reliability

Linear Technology's commitment to quality ensures that the LT3509IMSE#TRPBF meets the highest standards of performance and reliability. The product is designed to withstand harsh environments and is compliant with automotive standards for temperature and durability. Additionally, it is available in a RoHS-compliant package, making it suitable for environmentally sensitive applications.
