LTC2380IDE-24#PBF - 24-Bit SAR ADC from Linear Technology

The LTC2380IDE-24#PBF is a high-performance, 24-bit, low-noise Successive Approximation Register (SAR) Analog-to-Digital Converter (ADC) from Linear Technology, now part of Analog Devices. This precision ADC is designed for a wide array of applications requiring high accuracy and low power consumption, such as medical instrumentation, seismic data acquisition, and industrial process control.

Featuring an impressive 24-bit resolution, the LTC2380IDE-24#PBF offers a high level of precision and a noise-free resolution that ensures the integrity of the analog signal is maintained during the conversion process. The device operates from a 2.5V to 5.5V supply, making it versatile for various system voltage levels. Its wide input range and programmable gain options enable it to interface with a variety of sensors directly.

The LTC2380IDE-24#PBF boasts an impressive sample rate of up to 2Msps, providing a good balance between high-speed operation and low power consumption. This allows for real-time data acquisition and processing in demanding applications. The device also features an internal oscillator, eliminating the need for external components and simplifying the design process.

With SPI-compatible serial interface, the LTC2380IDE-24#PBF ensures easy integration with most microcontrollers and digital systems. It also includes a digital filter that reduces the noise and improves the signal-to-noise ratio, which is critical for applications where signal integrity is paramount.

The LTC2380IDE-24#PBF comes in a compact 14-lead DFN package with enhanced thermal performance, making it suitable for space-constrained applications. Its lead-free and RoHS-compliant design aligns with modern environmental standards, ensuring that the product can be used in various global markets.

In summary, the LTC2380IDE-24#PBF from Linear Technology is a state-of-the-art ADC offering exceptional performance, high resolution, and low power consumption. It is an ideal choice for designers looking to enhance the precision and efficiency of their data acquisition systems.
