The LTC2863CDD-1#PBF is a high-performance, robust RS485/RS422 transceiver from Linear Technology, designed to provide reliable communication in harsh environments. It is suitable for industrial, automotive, and communication network applications where noise immunity and high data integrity are paramount.

Key Features

• High Speed: This transceiver can operate at data rates up to 20Mbps, making it ideal for high-speed data communication requirements.
• Extended Temperature Range: The device is designed to operate reliably over a wide temperature range from -40°C to 125°C, ensuring performance in extreme conditions.
• Integrated Protection: It comes with integrated electrostatic discharge (ESD) protection up to ±15kV, ensuring robustness against transient voltage spikes.
• Fail-Safe Features: The LTC2863CDD-1#PBF includes fail-safe features that guarantee a high logic level receiver output when the receiver inputs are open or shorted, or if the transceiver is unpowered.
• Low Power: The device features a low operating current of 2.5mA, with a 1.7µA shutdown mode, which is beneficial for power-sensitive applications.

Applications

• Industrial Control Systems
• Automotive Networks
• Building Automation
• Factory Automation
• Instrumentation

Product Specifications

The LTC2863CDD-1#PBF transceiver is housed in a 10-lead DFN package with a compact footprint. It is designed for differential communication on a single pair of wires and is fully compliant with the TIA/EIA-485A standard. The product also features a half-duplex configuration, which allows for bidirectional communication over a single twisted-pair line.

Linear Technology ensures that the LTC2863CDD-1#PBF is a high-quality, reliable transceiver by subjecting it to rigorous testing and quality control measures. The product is RoHS compliant, adhering to environmental standards and regulations.
