Linear Technology's LTC3890EUH#TRPBF - Dual Output Step-Down Synchronous Controller

The LTC3890EUH#TRPBF is a high-performance, dual output synchronous step-down switching regulator controller designed by Linear Technology, which is now part of Analog Devices. This controller is capable of driving all N-channel power MOSFET stages, which enables the creation of high-efficiency power supplies that can deliver up to several amps of output current.

Encased in a compact 32-lead QFN (5mm x 5mm) package, the LTC3890EUH#TRPBF is designed for space-constrained applications while providing robust power management capabilities. It operates over a wide input voltage range from 4.5V to 38V, making it suitable for a variety of applications, including automotive, industrial, and telecommunications systems.

One of the key features of the LTC3890EUH#TRPBF is its powerful 1.1Ω onboard gate drivers, which are designed to minimize switching losses and improve overall efficiency. The device also offers a selectable fixed operating frequency from 50kHz to 900kHz or can be synchronized to an external clock signal in the same range, providing design flexibility and the ability to optimize for efficiency or component size.

The LTC3890EUH#TRPBF includes a range of protection features to ensure reliable operation under adverse conditions. These include overcurrent protection, overvoltage protection, and thermal shutdown. Additionally, the device supports output voltage tracking and soft-start features to enable a smooth power-up sequence for sensitive electronic loads.

For power system designers looking for a high degree of configurability, the LTC3890EUH#TRPBF offers programmable current limit, phase-lockable frequency (75kHz to 850kHz), and selectable Continuous, Pulse-Skipping, or Burst Mode operation at light loads. This versatility allows designers to tailor power solutions to specific needs, balancing performance, efficiency, and component size.

The LTC3890EUH#TRPBF is a testament to Linear Technology's commitment to providing advanced power management solutions that meet the demands of modern electronics. Its robust feature set, high efficiency, and compact form factor make it an excellent choice for a wide range of high-performance power supply designs.
