LTC6908HS6-1 Resistor Set Oscillator from Linear Technology

The LTC6908HS6-1 is a high-performance, low-power silicon oscillator from Linear Technology, designed to provide precision frequency generation with minimal external components. This oscillator is part of the LTC6908 series, which offers a range of frequency options to suit various applications in the electronics industry. The LTC6908HS6-1, in particular, is tailored for systems that require a fixed frequency that can be set using a single external resistor.

This compact oscillator is housed in a space-saving 6-lead TSOT-23 package, making it an ideal choice for space-constrained applications. It operates over a wide supply voltage range of 2.7V to 5.5V, ensuring compatibility with a variety of logic levels and power supplies. The device is characterized by its ease of use, requiring only a single resistor to set the frequency, thereby reducing the complexity of the design and the bill of materials.

The LTC6908HS6-1 is capable of generating frequencies from 50kHz to 10MHz, providing a versatile solution for applications such as switching regulators, clock generation, and data acquisition systems. The frequency of the oscillator can be precisely adjusted by selecting the appropriate value for the external resistor, and the part offers excellent frequency stability over temperature and supply variations.

Another key feature of the LTC6908HS6-1 is its ability to provide two output signals that are 180 degrees out of phase with each other. This can be particularly useful in applications that require a balanced push-pull signal, such as differential signaling or driving complementary power devices.

Linear Technology ensures that the LTC6908HS6-1 meets high-quality standards, with built-in features such as a proprietary linearization technique that minimizes the non-linearity of the resistor-to-frequency transfer function. This results in a highly accurate and stable frequency output that is critical for precision applications.

In summary, the LTC6908HS6-1 from Linear Technology is a versatile, easy-to-use, and reliable oscillator solution that provides designers with a simple way to generate precise frequencies using a single external resistor, all within a compact package suitable for a wide range of electronic applications.
