The LTM9001IV-GA#PBF is a high-performance, integrated data acquisition system from Linear Technology, now part of Analog Devices, designed to significantly streamline the design process for complex signal chain applications. This system-on-module (μModule®) solution is a complete, compact subsystem that includes a 14-bit, 125Msps analog-to-digital converter (ADC), matched with a high-performance differential amplifier and a precision voltage reference.

Key Features

• Integrated System: The LTM9001IV-GA#PBF combines an ADC, differential amplifier, and voltage reference in a single package, reducing design complexity and board space requirements.
• High-Speed ADC: With a 14-bit resolution and a sampling rate of 125Msps, this product offers excellent dynamic performance for demanding applications.
• Differential Amplifier: The onboard differential amplifier is optimized for driving the ADC, providing improved signal integrity and noise performance.
• Precision Voltage Reference: A stable and precise voltage reference ensures accurate ADC conversions, enhancing overall system accuracy.
• Easy Integration: Designed for ease of use, the LTM9001IV-GA#PBF can be integrated into a variety of designs with minimal external components required.
• Thermal Performance: The module is encapsulated in a compact, thermally enhanced package, ensuring reliable operation even in thermally challenging environments.

Applications

The LTM9001IV-GA#PBF is ideally suited for a wide range of applications that require high-speed, precision data acquisition. These include:

• Medical Imaging Systems
• Industrial Process Control
• Communications Infrastructure
• Aerospace and Defense Electronics
• Test and Measurement Equipment

Quality and Reliability

Linear Technology is renowned for its commitment to quality and reliability, and the LTM9001IV-GA#PBF is no exception. It is designed to meet stringent specifications and undergoes rigorous testing to ensure high performance and dependability for critical applications.
