The ME2N7002E-G is an N-channel enhancement mode MOSFET manufactured by Matsuki. It is designed for low-voltage switching applications, offering a combination of low on-resistance and fast switching speeds. The 'G' suffix indicates that it is a lead-free and RoHS compliant device.

Applications:

• Load switching
• DC-DC conversion
• Power management for portable devices
• LED driving
• Small motor control

Features:

• N-Channel enhancement mode MOSFET
• Low on-resistance (RDS(on)): Reduces power loss and improves efficiency.
• Fast switching speed: Allows for high-frequency operation.
• Low gate charge: Reduces driving power requirements.
• RoHS compliant: Environmentally friendly, free from hazardous substances.

Benefits:

• High efficiency: Low RDS(on) minimizes power dissipation.
• Fast switching: Suitable for high-frequency applications.
• Simplified driving circuitry: Low gate charge reduces driver complexity.
• Environmentally friendly: RoHS compliance ensures minimal environmental impact.
• Compact design: Typically available in small surface mount packages.

Specifications:

The ME2N7002E-G typically has a drain-source voltage (VDS) of 60V, a gate-source voltage (VGS) of ±20V, and a continuous drain current (ID) of approximately 0.2A. The RDS(on) is typically around 2 Ohms at a VGS of 10V. It is commonly packaged in a SOT-23 package. The operating temperature range is generally -55°C to +150°C.
