Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 70mV
Data Rate 2.5Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 089575-MAX491EESD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Industrial
Ultra Librarian 3D Model Ultra Librarian MAX491EESD CAD Model

Description

The MAX491EESD from Maxim Integrated is a robust and efficient transceiver module designed for RS-485 and RS-422 communication protocols. This device is tailored for long-distance and high-speed data transmission applications, making it an ideal choice for industrial networks, telecommunications, and other systems requiring reliable serial communication.

Key Features

  • Low Power Consumption: The MAX491EESD operates with a very low supply current, typically 300μA, making it suitable for power-sensitive applications.
  • Slew-Rate Limitation: It features a controlled slew rate, which limits the rate of change of the output signal, reducing EMI and reflections on improperly terminated buses.
  • Extended Temperature Range: The device is designed to operate over a wide temperature range, from -40°C to +85°C, ensuring reliability in harsh environments.
  • High Speed: With a data rate capability of up to 2.5Mbps, the MAX491EESD can handle high-speed data transmission with ease.
  • Half-Duplex Communication: The transceiver supports half-duplex communication, allowing bidirectional communication over a single pair of wires.
  • Robust Protection: It includes fail-safe features that guarantee a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all drivers disabled.

Applications

The MAX491EESD is versatile and can be used in a variety of applications such as:

  • Industrial Control Systems
  • Building Automation
  • Networked Security Systems
  • Data Acquisition Systems
  • Point-of-Sale Systems

Package and Reliability

Encased in a reliable SO package, the MAX491EESD ensures a compact footprint on printed circuit boards. Its integrated thermal shutdown and short-circuit protection features enhance the durability and longevity of the device, making it a dependable choice for critical communication systems.

With its combination of low power consumption, high-speed data transfer, and robust protection features, the MAX491EESD from Maxim Integrated stands out as a superior solution for RS-485/RS-422 transceiver needs in a wide array of applications.
