Product Overview: MAX6383XR29D3+T

Maxim Integrated's MAX6383XR29D3+T is a high-quality, precision microprocessor (µP) supervisory circuit designed to monitor power supplies in digital systems. It provides excellent circuit reliability and low cost by eliminating external components and adjustments when used in systems that require voltage monitoring.

Key Features

• Voltage Monitoring: This device features a factory preset V<sub>CC reset threshold voltage of 2.93V, ensuring that your system operates within its intended voltage range.
• Reset Output: The MAX6383XR29D3+T offers a reset output stage in push-pull configuration, which eliminates the need for an external pull-up resistor and can directly interface with other logic components.
• Power-On Reset Delay: It includes a 140ms minimum power-on reset delay which provides a stable system reset upon power-up, ensuring the µP starts in a known state.
• Low Power Consumption: Designed for energy-efficient systems, the device operates with a low quiescent current of only 5.5µA, making it ideal for battery-powered applications.
• Temperature Range: The MAX6383XR29D3+T is specified for operation over the extended -40°C to +125°C temperature range, suitable for various industrial environments.
• Small Form Factor: It is available in a small, 3-pin SC70 package, which is excellent for space-constrained applications.

Applications

The MAX6383XR29D3+T is versatile and can be used in a wide range of applications, including:

• Portable/Battery-Powered Equipment
• Computers and Controllers
• Embedded Systems
• Data Storage
• Medical Devices
• Automotive Systems

Reliability and Quality

Maxim Integrated is renowned for its commitment to quality and reliability, and the MAX6383XR29D3+T is no exception. It is designed to meet the stringent requirements of industrial applications and provides a robust power monitoring solution for critical systems.

In summary, the MAX6383XR29D3+T from Maxim Integrated is a reliable and cost-effective solution for systems that require precise voltage monitoring and reset capabilities. With its compact size, low power consumption, and robust feature set, it is an excellent choice for designers looking to enhance the reliability of their digital systems.
