Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Class D
Output Type 2-Channel (Stereo)
Max Output Power x Channels @ Load 22.5W x 2 @ 4 Ohm
Supply Voltage - Operating 4.5 V to 14 V
Features Depop, Mute, Short-Circuit and Thermal Protection, Shutdown, Volume Control
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 44-TQFN-EP (7x7)
Dimension 44-WFQFN Exposed Pad
Win Source Part Number 1071897-MAX9744ETH+
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX9744ETH+ CAD Model

Description

The MAX9744ETH+ from Maxim Integrated is a high-quality, 20W, stereo Class D audio power amplifier that delivers premium sound quality for a wide range of audio applications. With its efficient Class D operation, the MAX9744ETH+ provides excellent audio performance while minimizing power loss, making it an ideal choice for battery-powered devices, portable audio systems, and any application where power efficiency is crucial.

This audio amplifier integrates a digital volume control, which can be adjusted through either a digital I²C interface or an analog input, giving designers the flexibility to choose the best method for their specific application. The volume control range is from 0dB to -63dB with a mute function, allowing for precise sound level adjustments.

The MAX9744ETH+ operates over a wide supply voltage range from 4.5V to 14V, making it versatile for use in various electronic devices. It is designed to drive 4Ω to 8Ω speakers, and with its high 20W output power, it can easily fill a room with high-fidelity sound.

One of the key features of the MAX9744ETH+ is its click-and-pop suppression, which significantly reduces the noise that can occur when the device is turned on or off. This feature enhances the user experience by providing a smoother transition during power cycling.

Safety is a priority with the MAX9744ETH+, as it includes comprehensive protection against faults. It features overcurrent, thermal, and undervoltage lockout protection, ensuring reliable operation under various conditions and protecting both the amplifier and the speakers from potential damage.

The MAX9744ETH+ comes in a thermally efficient 28-pin TSSOP package with an exposed pad. This packaging not only aids in heat dissipation but also allows for a more compact design, which is beneficial for space-constrained applications.

In summary, the Maxim Integrated MAX9744ETH+ stereo audio amplifier is a high-performance, versatile solution that offers excellent sound quality, efficient power management, and robust protection features. It is suitable for a broad range of audio applications, from portable speakers to home audio systems.
