ESD0524P

Part No ESD0524P
Manufacturer MDD
Catalog TVS - Diodes
Description TVS DIODE 5VWM 12VC DFN2510-10L
Datasheet
ESD0524P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr MDD
Series DFN2510
Package Tape & Reel
Product Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6V
Voltage - Clamping (Max) @ Ipp 12V
Current - Peak Pulse (10/1000µs) 3.5A (8/20µs)
Power - Peak Pulse 60W
Power Line Protection Yes
Applications DVI, HDMI
Capacitance @ Frequency 0.5pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C
Mounting Type Surface Mount
Package / Case 10-UFDFN
Supplier Device Package DFN2510-10L
Standard Package 6,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 589883-ESD0524P
Ultra Librarian 3D Model Ultra Librarian ESD0524P CAD Model

Description

The ESD0524P is a steering TVS diode designed for circuit protection in DVI and HDMI applications.

  • Reverse Standoff Voltage: 5V
  • Breakdown Voltage: 6V
  • Peak Pulse Power: 60W
  • Type: Unidirectional TVS diode with four channels
  • Package: Compact DFN2510 package
  • Capacitance: 0.5pF @ 1MHz
  • Temperature Range: -55°C to 150°C
  • Series: MDD
