The Meder Electronic ORD324 is a normally open (1 Form A) reed relay designed for various switching applications. This relay is characterized by its compact size, high insulation resistance, and fast switching speed. It’s suitable for use in telecommunications, instrumentation, and automated test equipment.

Applications

• Telecommunications equipment
• Instrumentation
• Automated test equipment (ATE)
• Security systems
• Medical equipment

Features

• Normally Open (1 Form A) configuration
• High insulation resistance
• Fast switching speed
• Compact size
• RoHS compliant
• Low contact resistance

Benefits

• Reliable switching performance
• High isolation between control and load circuits
• Quick response time for high-speed applications
• Space-saving design for compact equipment
• Long operating life

Additional Details

The ORD324 typically operates with a coil voltage of 5V or 12V, depending on the specific model. It can switch voltages up to 200VDC and currents up to 0.5A. The insulation resistance is typically greater than 10^12 ohms. The switching time is typically less than 1 millisecond. The relay is available in various package styles, including SIP and DIP. It's designed for applications where reliable switching and high isolation are critical. The fast switching speed allows for use in high-speed data acquisition and control systems. The compact size makes it suitable for densely populated PCBs. The ORD324 is commonly used in telecommunications equipment for signal routing and switching. It's also used in instrumentation for accurate and reliable measurements. In automated test equipment, it provides a fast and reliable means of switching test signals. The relay's long operating life ensures minimal maintenance and replacement. The hermetically sealed reed switch provides excellent environmental protection, ensuring reliable operation in harsh conditions.
