MIC5301YD5 Real Image MIC5301YD5 Real Image
Same model may have multiple batches, images only for reference.
MIC5301YD5 Real Image MIC5301YD5 Real Image
MIC5301YD5 Real Image MIC5301YD5 Real Image
Same model may have multiple batches, images only for reference.

MIC5301YD5

Part No MIC5301YD5
Manufacturer Micrel
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR SGL 150 MICRO AMP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Micrel
Package Bulk
Product Status Active
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 5.5V
Voltage - Output (Min/Fixed) 1.25V
Voltage - Output (Max) 5.5V
Voltage Dropout (Max) 0.1V @ 150mA
Current - Output 150mA
Current - Quiescent (Iq) 120 µA
PSRR 75dB ~ 50dB (1kHz ~ 20kHz)
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case SOT-23-5 Thin, TSOT-23-5
Supplier Device Package TSOT-23-5
Standard Package 1 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 640262-MIC5301YD5
Ultra Librarian 3D Model Ultra Librarian MIC5301YD5 CAD Model

Description

The MIC5301YD5 is a voltage regulator from Micrel. It is part of the integrated circuits (ICs) power management (PMIC) series and falls under the category of linear voltage regulators.

  • Package: bulk package
  • Standard Package Quantity: 1 piece
  • Current Output: 150mA
  • Output Type: adjustable output type
  • Control Features: enable functionality
  • Maximum Output Voltage: 5.5V
  • Input Voltage: up to 5.5V
  • Mounting: surface mountable
  • Package: SOT-23-5 thin package
  • PSRR (power supply rejection ratio): 75dB to 50dB @ frequencies ranging from 1kHz to 20kHz
  • Protection Features: over current and over temperature protection
  • Current Quiescent (Iq): 120 μA
  • HTSUS Code: 8542.39.0001
  • Product Status: active
