3SMAJ5927B-TP Real Image 3SMAJ5927B-TP real image22217
Same model may have multiple batches, images only for reference.
3SMAJ5927B-TP Real Image 3SMAJ5927B-TP real image22217
3SMAJ5927B-TP Real Image 3SMAJ5927B-TP real image22217
Same model may have multiple batches, images only for reference.

3SMAJ5927B-TP

Part No 3SMAJ5927B-TP
Manufacturer Micro Commercial Co
Catalog Diodes - Zener - Single
Description DIODE ZENER 12V 3W DO214AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Micro Commercial Co
Packaging Reel
Voltage - Zener (Nom) (Vz) 12V
Tolerance ±5%
Power - Max 3W
Impedance (Maximum) (Zzt) 6.5 Ohms
Current - Reverse Leakage at Vr 1μA at 9.1V
Voltage - Forward (Vf) (Maximum) at If 1.5V at 200mA
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Manufacturer Package DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
Part Number Series SMAJ5927
Manufacturer Pack Quantity 7,500
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Balance
Win Source Part Number 802640-3SMAJ5927B-TP
Ultra Librarian 3D Model Ultra Librarian 3SMAJ5927B-TP CAD Model

Description

The SMAJ5927B-TP from Nexperia USA Inc. is a zener diode.

  • Voltage Rating: 12V
  • Power Rating: 3W
  • Tolerance: ±5%
  • Impedance: 6.5 Ohms
  • Current Rating: 200mA
  • Reverse Leakage Current: 1μA @ 9.1V
  • Package: DO-214AC (SMA)
  • Temperature Range: -55°C to 150°C
