ESD5V0D5-TP Real Image ESD5V0D5-TP real image15408 ESD5V0D5-TP real image15409 ESD5V0D5-TP real image15410
Same model may have multiple batches, images only for reference.
ESD5V0D5-TP Real Image ESD5V0D5-TP real image15408 ESD5V0D5-TP real image15409 ESD5V0D5-TP real image15410
ESD5V0D5-TP Real Image ESD5V0D5-TP real image15408 ESD5V0D5-TP real image15409 ESD5V0D5-TP real image15410
Same model may have multiple batches, images only for reference.

ESD5V0D5-TP

Part No ESD5V0D5-TP
Manufacturer Micro Commercial Co
Catalog TVS - Diodes
Description TVS DIODE 5VWM 11.6VC SOD523
Datasheet
ESD5V0D5-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6.2V
Max Clamping Voltage 11.6V
Power Dissipation - Pd 174W
Applications General Purpose
Capacitance @ Frequency 80pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-523
Win Source Part Number 1037068-ESD5V0D5-TP
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 8k pcs
Ultra Librarian 3D Model Ultra Librarian ESD5V0D5-TP CAD Model

Description

The Micro Commercial Co ESD5V0D5-TP is a unidirectional zener diode designed for general purpose applications.

  • Type: Unidirectional Zener Diode
  • Application: General Purpose
  • Mounting Type: SMD (SMT)
  • Capacitance: 80pF @ 1MHz
  • Stand-Off Voltage: 5V
  • Breakdown Voltage (Min): 6.2V
  • Clamping Voltage (Max): 11.6V
  • Peak Pulse Current: Not Specified
  • Power Dissipation: 174W
  • Temperature Range: -55°C to 150°C (TJ)
  • Packaging: Reel - TR
  • Popularity: Medium
  • Quantity per Package: 8k pcs
