MMBT2222A-TP Real Image MMBT2222A-TP real image10741
Same model may have multiple batches, images only for reference.
MMBT2222A-TP Real Image MMBT2222A-TP real image10741
MMBT2222A-TP Real Image MMBT2222A-TP real image10741
Same model may have multiple batches, images only for reference.

MMBT2222A-TP

Part No MMBT2222A-TP
Manufacturer Micro Commercial Co
Catalog Transistors (BJT) - Single
Description TRANS NPN 40V 0.6A SOT23
Datasheet
MMBT2222A-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 600mA
VCEO Maximum Collector-Emitter Breakdown Voltage 40V
Max Vce (sat) 1V @ 50mA, 500mA
Typical Gain (hFE) (Min) 100 @ 150mA, 10V
Maximum Power Dissipation 350mW
Frequency - Transition 300MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23
Win Source Part Number 1078258-MMBT2222A-TP
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MMBT2222A-TP CAD Model

Description

The Micro Commercial Co MMBT2222A-TP is an active electronic component that is balanced in terms of supply and demand.

  • Manufacturer: Micro Commercial Co
  • Product: MMBT2222A-TP
  • Status: Active
  • Supply and Demand: Balanced
  • Mounting Type: Surface mount
  • Transistor Type: NPN
  • Maximum Collector-Emitter Breakdown Voltage: 40V
  • Maximum Current Collector: 600mA
  • Maximum Power Dissipation: 350mW
  • Typical Gain (hFE): 100 @ 150mA and 10V
  • Frequency Transition: 300MHz
  • Package Quantity: 3k pieces
